5130 Kit for experiments on the electric circuits
To be used with an electric, low-voltage power unit ,which can be adjusted from 0 to 12V.
Structure made of painted metal.
Panel dimensions: 57×33 cm.
Topics
• The electric circuit
• Use of the instruments
• Verification of Ohm’s first law
• Dependence of resistance on temperature
• Lamps in series
• Lamps in parallel
• Resistances in series
• Resistances in parallel
• Electrical net
Equipment supplied
4 Electrical leads 30 cm
2 Electrical leads 100 cm
2 Iron holders for panel
1 Panel with instruments
1 Plate for circuits
10 Bridges with short-circuit
2 Bridges with lamp
2 Bridges with switch
1 Resistor bridge = 12 Ω
1 Resistor bridge = 18 Ω
1 Resistor bridge = 56 Ω
1 Resistor bridge = 100 Ω
1 Resistor bridge = 120 Ω
